Motorola MOTOTRBO R7

Break Through the Noise. Be Heard

MOTOTRBO R7 is a digital portable two-way radio that offers game-changing audio capabilities in a rugged, future-ready device. Its advanced audio processing ensures that your communications are loud and clear, while its rugged construction is ready for harsh environments, and advanced connectivity options get your workforce ready for tomorrow.

Sharp, Clear Audio
MOTOTRBO R7 lets your team hear and be heard the first time — when it matters most. Adaptive Dual Microphone Noise Suppression brings game-changing noise canceling to your team, so you can hear them over the deafening noise of heavy machinery, a roaring stadium at full capacity, or wherever they are. Automatic Acoustic Feedback Suppression intelligently cancels out the feedback of other close-by radios, for a seamless voice experience in tightly packed areas. Intelligent Audio monitors background noise and adjusts speaker volume so users don’t have to, ensuring calls are always at the perfect volume.

Be Heard Above All Else
MOTOTRBO R7 delivers unprecedented loudness, so your team can hear in any situation. Its powerful speaker delivers a booming loudness of 102 phons, four times louder than a shouting conversation. R7 also features a programmable extra loud profile, bringing total loudness to 107 phons on the radio and with the remote speaker microphone — four times louder than a motorcycle at close range.

Customizable Audio Experience
MOTOTRBO R7 can be adapted with accessories that are specially designed to make your fleet easier to use and even more capable, especially in loud environments. Its re-engineered accessory port adds more robustness and longevity to the point where your accessories connect to the radio, while making it more resistant to dust and corrosion. Remote speaker microphones and other audio accessories let you quickly reach and use your radio. R7’s extra loud profile can be supported by several purpose-built. And our IMPRES™ technology ensures that R7 works seamlessly with your Motorola Solutions accessories, so every call is heard perfectly.

Motorola MOTOTRBO R7 Key Features

• UHF/VHF
• Wi-Fi 2.4/5.0 GHz
• WPA3 Wi-Fi security protocol compliant
• Bluetooth 5.2
• 2.4" 320 x 240 px. QVGA display
• Automatic Acoustic Feedback Suppression
• Adaptive Dual Microphone Noise Suppression
• Intelligent Audio
• IMPRES™ technology
• Programmable loudness up 107 phons
• Wideband speaker and microphones
• Up to 28 hours of battery life
• IP68 (waterproof up to 2 meters for 2 hours)
• IP66 (concentrated water jet pressure)
• Intrinsically safe option (UL TIA-4950)
• Rugged to MIL-STD 810
• 5 years of hardware repair, technical support, software updates and premium features

Brochures

• Motorola MOTOTRBO R7 Brochure
• Motorola MOTOTRBO R7 Brochure - Healthcare
• Motorola MOTOTRBO R7 Brochure - Manufacturing
• Motorola MOTOTRBO R7 Brochure - Transportation and Logistics

Catalogs

• Motorola MOTOTRBO Accessory Catalog

Data Sheets

• Motorola MOTOTRBO R7 Data Sheet
• Motorola MOTOTRBO R7 Contactless Solutions Data Sheet
• Motorola & Honeywell Connected Safety Solution Data Sheet

Whitepapers

• Motorola MOTOTRBO R7 - Be Heard

Videos

MOTOTRBO R7 Demo: Enhanced Audio Capabilities

The MOTOTRBO R7 radio features advanced audio technology such as Adaptive Dual Microphone Noise Suppression & Automatic Acoustic Feedback Suppression for clear communication, even in loud environments. With intelligent audio & audio playback feature, users can focus on the task at hand.

MOTOTRBO R7 Demo: Form Factor and Size

The MOTOTRBO R7 radio - our most ergonomic yet, with a slim design, large display, and unbeatable durability. Its IP66 and IP68 ratings make it dust tight and protected from water immersion. The redesigned accessory port is waterproof and dustproof, and it fits comfortably in your hand, on your belt, or even in your pocket. The perfect combination of size, performance, and ruggedness!

MOTOTRBO R7 Demo: Intuitive User Interface

The MOTOTRBO R7 radio boasts an advanced physical design, optimized emergency button, large 2.4" display, and intuitive knob design for efficient communication. Its improved keypad, larger screen and optimized digital interface make it easy to use and navigate.

The Motorola MOTOTRBO R7 is available in the following models.

Non-Display CAPABLE Models

• AAH06JDC9WA1AN VHF, 136-174 MHz, 5 Watts, 64 Channels, Wi-Fi Capable
• AAH06RDC9WA1AN UHF, 403-512 MHz, 4 Watts, 64 Channels, Wi-Fi Capable
• AAH06UCC9WB1AN 800/900, 806-941 MHz, 2.5 Watts, 64 Channels, Wi-Fi Capable

Non-Display ENABLED Models

• AAH06JDC9RA1AN VHF, 136-174 MHz, 5 Watts, 64 Channels, Wi-Fi Enabled
• AAH06RDC9RA1AN UHF, 403-512 MHz, 5 Watts, 64 Channels, Wi-Fi Enabled
• AAH06UCC9RB1AN 800/900, 806-941 MHz, 2.5 Watts, 64 Channels, Wi-Fi Enabled

Display CAPABLE Models

• AAH06JDN9WA1AN VHF, 136-174 MHz, 5 Watts, 1000 Channels, Wi-Fi Capable
• AAH06RDN9WA1AN UHF, 403-512 MHz, 5 Watts, 1000 Channels, Wi-Fi Capable
• AAH06UCN9WB1AN 800/900, 806-941 MHz, 2.5 Watts, 1000 Channels, Wi-Fi Capable

Non-Display ENABLED Models

• AAH06JDN9RA1AN VHF, 136-174 MHz, 5 Watts, 1000 Channels, Wi-Fi Enabled
• AAH06RDN9RA1AN UHF, 403-512 MHz, 5 Watts, 1000 Channels, Wi-Fi Enabled
• AAH06UCN9RB1AN 800/900, 806-941 MHz, 2.5 Watts, 1000 Channels, Wi-Fi Enabled
